GZY-A8520
ABS On Metal RFID Tags
A grey-black ABS material label, with dimensions of 85×20×11mm.It is thick and durable. The farthest reading distance on the metal surface is 12 meters. It supports surface printing customization and is suitable for industrial scenarios such as medium and large-sized equipment, shelves, etc., where stable long-distance identification is required.
/
Micro anti - metal RFID tag
Features
-
Compact 85x20mm -
Maximum 12 Meters -
IP68 Protection Rating -
Customizable Surface Printing -
Wide Operating Temperature Range -
Adhesive/Screw/Cable Tie
Specifications
-
Physical Features
Model GZY-A8520 Size 85(L)x20(W)x11.0(H)mm, (Hole:D4.0mmx2)
Material ABS+PC
Working Temp -25~+85℃
Storage Temp -40~+85℃
Installation Methods Adhesive, Screw, binding
Package details 500Pcs/bags
Weight 10.0g
Colour White -
RFID Features
Protoccol Standard EPC CLASS1 GEN2, ISO 18000-6C
Working Frequency 865-868Mhz, 902-928Mhz(Customized)
Chip Type NXP Ucode 8, 9，Impinj M730
EPC Memory 96-128bit, TID:64bit
Read distance 1-12.0m, On Metal Surfaces (depend on working environment)
Re-Write >100,000times
Data Storage >10 years
-
Others Features
Application ● IT Asset Management
● Production line Management
● Medical Equipment Management
● Fixed Asset Management
optional Customization Surface laser, printing LOGO, serial number, Encoding, etc
IP Rating IP68
